The John Deere 6130M is a 2WD or 4WD utility tractor from the 6M series. This tractor was manufactured by John Deere in Mannheim, Baden-Württemberg, Germany from 2015 to 2022. THis first generation was manufactured from 2015 to 2020. The JD 6130M is equipped with a 4.5 L (276.0 cu·in) four-cylinder diesel engine and one of four transmission variants.
The John Deere 6130M utility tractor used the John Deere PowerTech PSS engine. It is a 4.5 L, 4,523 cm2, (276.0 cu·in) four-cylinder turbocharged aftercooled diesel engine with 105.0 mm (4.13 in) of the cylinder bore and 127.0 mm (5.00 in) of the piston stroke. This engine produced 131.8 PS (96.9 kW; 130.0 HP) at 2,100 rpm of output power.
The JD 6130M is equipped with power steering, hydraulic wet disc brakes, cab (standard) with air-conditoning or two-post folding ROPS and 193.0 liters (51.0 US gal.; 42.5 Imp. gal) fuel tank.
Following attachments are available for the John Deere 6130M utility tractor:
- John Deere 620R loader
- John Deere 640R loader
John Deere 6130M Specifications
| General Specifications | |
| Model | John Deere 6130M |
| Length | 4,480 mm (176.4 in) |
| Width | 2,550 mm (100.4 in) |
| Height | ROPS: 2,870 mm (113 in) Cab: 2,870 mm (113 in) |
| Wheelbase | 2,580 mm (101.6 in) |
| Ground clearance (front axle) | 600 mm (23.6 in) |
| Weight | 5,225 kg (11,519 lbs) |
| Fuel tank capacity | 193.0 liters (51 US gal.; 42.5 Imp. gal) |
| Battery | 12V |
| Cabin type | Cab (standard) with air-conditoning or two-post folding ROPS |
| Engine | |
| Engine model | John Deere PowerTech PSS |
| Engine type | Four-stroke, liquid-cooled, inline |
| Cylinders | 4 |
| Fuel type | Diesel |
| Displacement | 4.5 L, 4,523 cm2, (276.0 cu·in) |
| Bore and stroke | 105.0 mm X 127.0 mm (4.13 in X 5 in) |
| Horsepower | 131.8 PS (96.9 kW; 130.0 HP) at 2,100 rpm |
| Starter | Electric |
| Coolant capacity: | 22.0 L (23.2 US. qt, 19.4 Imp. qt.) |
| Transmission and chassis | |
| Chassis | 4×2 2WD or 4×4 MFWD 4WD |
| Steering type | Power |
| Brakes | Hydraulic wet disc |
| Final drive | Inboard planetary |
| Differential lock | Electro-hydraulic front and rear |
| Transmission model | SyncroPlus |
| Transmission type | – |
| Gears | 12 forward and 4 reverse |
| Transmission model | PowrQuad |
| Transmission type | Four-speed power shift with wet disc clutch |
| Gears | 16 forward and 16 reverse |
| Speed | Forward: 30.1 kmh (18.7 mph) |
| Transmission model | PowrQuad |
| Transmission type | Four-speed power shift with wet disc clutch |
| Gears | 24 forward and 24 reverse |
| Speed | Forward: 37.5 kmh (23.3 mph) |
| Transmission model | AutoQuad PLUS |
| Transmission type | Four-speed power shift with wet disc clutch |
| Gears | 24 forward and 24 reverse |
| Speed | Forward: 37.5 kmh (23.3 mph) |
| Tires | |
| Front tires | Ag: 10.00-16 (2WD), 380/85R28 (4WD) |
| Rear tires | Ag: 460/85R38 |
| Three-Point Hitch | |
| Category | IIIN/II |
| Control type | Electronic lower-link draft sensing |
| Lift capacity (at ends) | 2,936 kg (6,475 lbs) 3,835 kg (8,456 lbs) |
| PTO (Power take-off shaft) | |
| Rear PTO type | Independent with electro-hydraulic clutch |
| Rear PTO speed | 540/1000 or 540 rpm |
| Hydraulic system | |
| Hydraulic type | Open center or closed-center pressure-and-flow compensated load sensing |
| Pressure | 2900 psi (199.9 bar) |
| Valves | Rear: 3 Mid: 3 |
| Pump flow | 21.1 gpm (79.9 lpm) 30.0 gpm (113.6 lpm) |
| SCV flow | 21.1 gpm (79.9 lpm) |
