Toro Wheel Horse 518xi

Toro Wheel Horse 518xiThe Toro Wheel Horse 518xi is a 2WD garden tractor from the 5xi series. This tractor was manufactured by Toro from 1998 to 2002. The Toro Wheel Horse 518xi is equipped with a 0.6 L (38.1 cu·in) two-cylinder gasoline engine and a shaft-driven hydrostatic transmission with infinite forward and reverse (2-range) gears.

The Toro Wheel Horse 518xi garden tractor used the Kohler CH18 engine. It is a 0.6 L, 624 cm2, (38.1 cu·in) two-cylinder natural aspirated gasoline engine with 77.0 mm (3.03 in) of the cylinder bore and 67.0 mm (2.64 in) of the piston stroke. The compression ratio rating is 8.5:1. This engine produced 18.2 PS (13.4 kW; 18.0 HP) at 3,600 rpm of output power.

The Toro Wheel Horse 518xi is equipped with manual steering, open operator station and 16.1 liters (4.3 US gal.; 3.5 Imp. gal) fuel tank.

Following attachments are available for the Toro Wheel Horse 518xi garden tractor:

  • Mid-mount Toro Wheel Horse 78353 42 in (1,060 mm) mower deck with 3-blade, rear-discharge and hydraulic lift
  • Mid-mount Toro Wheel Horse 78357 44 in (1,110 mm) mower deck with 3-blade, right-discharge and hydraulic lift
  • Mid-mount Toro Wheel Horse 78363 48 in (1,210 mm) mower deck with 3-blade, right-discharge and hydraulic lift
  • Mid-mount Toro Wheel Horse 78375 52 in (1,320 mm) mower deck with 3-blade, right-discharge and hydraulic lift
  • Front-mount Toro Wheel Horse 79355 48 in (1,210 mm) blade
  • Front-mount Toro Wheel Horse 79365 42 in (1,060 mm) single-stage snow blower
  • Front-mount Toro Wheel Horse 79366 44 in (1,110 mm) two-stage snow blower
  • Front-mount Toro Wheel Horse 79947 loader

Toro Wheel Horse 518xi Specifications

General Specifications
ModelToro Wheel Horse 518xi
Length1,940 mm (76.4 in)
Width1,020 mm (40.2 in)
Height
Wheelbase1,320 mm (52 in)
Weight459 kg (1,012 lbs)
Fuel tank capacity16.1 liters (4.3 US gal.; 3.5 Imp. gal)
Battery12V, CCA 380A
Cabin typeOpen operator station
Engine
Engine modelKohler CH18
Engine typeFour-stroke, air-cooled, V
Cylinders2
Fuel typeGasoline
Displacement0.6 L, 624 cm2, (38.1 cu·in)
Bore and stroke77.0 mm X 67.0 mm (3.03 in X 2.64 in)
Compression ratio8.5:1
Horsepower18.2 PS (13.4 kW; 18.0 HP) at 3,600 rpm
StarterElectric
Oil typeSAE 10W-30
Oil capacity:1.9 L (2 US. qt, 1.7 Imp. qt.)
Spark plugChampion RC12YC
Transmission and chassis
Chassis2WD
Steering typeManual
Brakes
Transmission modelEaton Uni-Drive
Transmission typeShaft-driven hydrostatic
GearsInfinite forward and reverse (2-range)
Speed Forward: 12.1 kmh (7.5 mph) Reverse: 5.5 kmh (3.4 mph)
Tires
Front tires Lawn/turf: 16×7.5
Rear tires Lawn/turf: 23×10.50
PTO (Power take-off shaft)
Front PTO typeIndependent with electric clutch
Front PTO speed
